Delevan S4924-565H

Part No.:
S4924-565H
Manufacturer:
Delevan
Category:
Fixed Inductors
Package:
Nonstandard
Datasheet:
AnpuS4924-565H.pdf
Description:
FIXED IND 5.6MH 61MA 98.9OHM SMD
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:23,858

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity*
Price
Name*
Company*
Email*
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Delevan
Series:
S4924
Package/Case:
Nonstandard
Packaging:
Tape & Reel (TR)
Product Status:
Active
Type:
-
Material - Core:
Ferrite
Inductance:
5.6 mH
Tolerance:
±3%
Current Rating (Amps):
61 mA
Current - Saturation (Isat):
14mA
Shielding:
Shielded
DC Resistance (DCR):
98.9Ohm Max
Q @ Freq:
50 @ 250kHz
Frequency - Self Resonant:
1.6MHz
Ratings:
-
Operating Temperature:
-55°C ~ 125°C
Inductance Frequency - Test:
250 kHz
Features:
-
Mounting Type:
Surface Mount
Supplier Device Package:
-
Size / Dimension:
0.520" L x 0.250" W (13.21mm x 6.35mm)
Height - Seated (Max):
0.230" (5.84mm)
